They are distinguished for:
- Easy and fast standard mounting
- Excellent weather and corrosion resistance
- Very good bearing capacity as a roof profile
- Excellent water flow due to the profile grooves
Produced with:
- Cover width of 768mm and 896mm, in various thicknesses of metal sheet
- in lengths from 1m to 12m, depending on the project
Available Coatings and Paints
Classic Polyester Paint
Polyester paints are the most common and most economical metal sheet coatings. They are suitable for both external and internal surfaces. With a nominal coating thickness of > 20µm they have a very good resistance to external environmental conditions.
Durable Plastisol Paint
Plastisol coating is very durable to external environment. It belongs to the category of “self-healing” coatings on mechanical damage. With a nominal coating thickness of 200μm it is suitable for outdoor applications where the requirements are high.
High req PVDF paint
PVDF coating is suitable for buildings of architectural applications where the texture and color conservation are important. Also its reaction to fire is excellent because it has limited production of smoke, class S1. The nominal thickness is > 35mm.
Color Coating Options
An extremely large number of color coating options are available. Please refer to our sales department for the available colors (RAL 1014 to RAL 9010).
Essential Properties
| Profile Type | Cover Width [mm] | Development [mm] | Steel Weight [kg/m]* | Aluminum Weight [kg/m]* |
| Trapezoidal profile 39/128 | 768 | 1100 | 4,32 | 1,51 |
| Trapezoidal profile 39/128 | 896 | 1250 | 4,91 | 1,72 |
| Trapezoidal profile 42/250 | 1000 | 1250 | 4,91 | 1,72 |
* Weight per unit length was calculated taking into account the nominal thickness 0,50mm of metal sheets and the specific weight of steel 7850 kg/m3 and aluminum 2750 kg/m3.
Accessories / Items
